8-Port PoE+ Ethernet Switch with 2 Uplink Ports – 115W PoE Budget, 250m Extend Mode

The 8-Port PoE+ Ethernet Switch is a perfect plug-and-play solution for home and small business networks. Featuring 8 PoE ports with power delivery of up to 30W per port and 2 uplink ports, this switch provides seamless data and power transmission over Ethernet cables. It’s a non-programmable switch, meaning there are no complex settings involved. The switch supports an extended mode of up to 250 meters, allowing for longer network distances, perfect for **IP cameras**, **VoIP phones**, or **wireless access points**.

Key Features of the 8-Port PoE+ Ethernet Switch





Network Connector:



8+2 RJ45 ports for 10/100BASE-TX Ethernet with auto MDI/MDIX







PoE Ports:



8 PoE ports with 802.3af/at injector function, up to 30W per port







Switch Fabric:



2Gbps







Switch Throughput:



1.48Mpps @ 64 bytes







PoE Power Budget:



115W







Dimensions:



200x160x40 mm



Detailed Hardware Specifications





Network Connector:



8+2-port RJ45 for 10/100BASE-TX, auto MDI/MDIX







PoE Inject Port:



8-port with 802.3af/at PoE injector function (Port 1 to Port 8)







LED Display:



System Power (Green), PoE status per port, LNK/ACT for uplink ports







Switch Architecture:



Store and Forward







MAC Address Table:



2K MAC address table with auto learning







Switch Fabric:



2Gbps







Switch Throughput:



1.48Mpps @ 64 bytes



Power over Ethernet (PoE) Features





PoE Standard:



IEEE 802.3af/at







PoE Power Output:



Max 15.4W per port (802.3af), max 30W per port (802.3at)







PoE Power Budget:



115W







PoE Pin Assignment:



1/2(+), 3/6(-)



Environmental Specifications





Operating Environment:



0 ~ 50°C







Storage Environment:



-10 ~ 70°C







Humidity:



5 ~ 95%, non-condensing



Power Specifications





Power Requirements:



52V 2.3A, built-in power supply (optional)







Dimensions:



200x160x40 mm



Why Choose This PoE+ Ethernet Switch?

This **8-Port PoE+ Ethernet Switch** is designed for users who need a simple, **non-programmable** solution to provide power and data to multiple devices. Its **plug-and-play** nature means no configuration is required, making it easy to set up and ideal for small businesses, homes, or simple network setups. With its **115W PoE budget**, it can power **IP cameras**, **VoIP phones**, or **wireless access points**. The 2 uplink ports allow you to connect to another network switch or your router without sacrificing PoE ports.

The **250m extend mode** allows for long-distance connections, making it suitable for larger installations like warehouses, parking lots, or offices. The durable construction and **wide temperature range** ensure reliable performance in various environments, even in harsh conditions.

Perfect for non-technical users, this switch provides reliable connectivity without any need for complex management or programmable settings, making it a cost-effective, efficient solution for both **small businesses** and **home networks**.
